A
XON Digital Plat
f
orm
User Manual
Revision A
125
©
2019 MST Global Commercial in Confidence
Appendix H: AXON Core Specifications
General
Dimensions 360mm x 507mm x 146mm (H x W x D) – without mounting bracket
Weight 9.0kg packaged
Connectivity 3 x MST composite fibre ports (1000BASE-LX)
4 x IEEE 802.3at PoE+ ports (1000BASE-T)
2 x MST Expansion Slots (proprietary modular interfaces)
1 x DataKey RUGGEDrive slot (configuration management port)
1 x Mechanical mount to support an MST AXON Air wireless module
Enclosure Ingress
Protection (IP) rating
SMC enclosure, sealed to comply with an Ingress Protection standard
rating of IP65
Operating Temperature 0ºC to 50ºC (operating)
-20ºC to 80ºC (storage)
Operating Humidity 5- 95%
Power
Supply Voltage 20-60 VDC operation
External Power Supply
Recommendations
A
C to DC power supply with galvanically isolated output(s)
56VDC output(s) (nominal)
With 6A breaker/fusing in line with each 56V output
Power
Consumption
Part Number Configuration Idle (W) Maximu
m (W)
A
XON Core 56VDC input voltage,
No AXON Air or PoE+ devices connected
10.50 12.50
A
XON Core + AXON Air
(locally mounted)
56VDC input voltage,
1 x AXON Air (zero metres of CAT5 cable)
14.50 18.50
A
XON Core + AXON Air
(
r
emotely mounted)
56VDC input voltage,
1 x AXON Air (100 metres of CAT5 cable)
14.52 18.55
A
XON Core + 2 AXON
A
ir (daisy chained)
56VDC input voltage,
1 x AXON Air (100 metres of CAT5 cable) +
1 x daisy chained AXON Air (100m CAT5)
18.62 24.77
A
XON Core + 3 AXON
A
ir (daisy chained)
56VDC input voltage,
1 x AXON Air (100 metres of CAT5 cable) +
1 x daisy chained AXON Air (100m CAT5) +
22.84 31.30
