MST AXON User Manual

86
©
2019 MST Global Commercial in Confidence
A
XON Digital Plat
f
orm
User Manual
Revision A
The parameters shown in the example device configuration file are described in the following table.
Section Parameter Description Settings
System system.hostname
Network switch
name.
Each device should have a unique name
identifier.
System system.location
Location name of
the network switch.
It is recommended the location name is
relevant to the physical location of the
device.
Wireless Radio
Configuration
w
ireless.radio.1.channel Wi-Fi channel that
the WAC will
operate on.
It is recommended WACs in proximity of
each other have assigned channels 1, 6
and 11. This minimises signal overlap and
interference.
Power over
Ethernet
switch.poe.enabled Enabling PoE
supply on the
network switch.
0 = Disabled, 1 = Enabled
NOTE: This setting is not applicable to
WAPs and will be ignored when the file is
applied to a WAP.
To edit a device configuration file:
3. Open a text file editor on your PC.
4. Locate and open the device configuration file ap_MACaddress_settings.conf. This is usually
stored in the file directory folder of the TFTP server.
5. Edit the parameters as required.
6. In the directory folder of the TFTP server, save the file using the naming
ap_MACaddress_settings.conf, where MACaddress is the MAC address of the WAC card to
configure.
8.3 TFTP Parameters
Below is a list of configurable parameters for AXON Core, classified by type.
Network
Common LAN settings to all devices on a network as shown below.
Field Description
network.1.addr.mode
0
: Static - fixed IP address configured manually on the device
1
: DHCP - IP address assigned automatically
network.1.addr.static The IP address of the device, if Static.
network.1.netmask Identifies the subnet the IP address belongs to for the device.
