Belt ‒ Application Measured value
Initial installation (new belt)
Measured value
Operating tension (used belt)
Drive belt – Battery-charging gen-
erator
Depression depth: 7.8 mm
Test force: 60 N
Depression depth: 8.9 mm
Test force: 60 N
Table 116: Set-point values ‒ Measurement with preload measuring device
8. Tighten screws (1).
9. Use nut (5) to fasten the clamping bolt (4).
Final steps
1. Install protective cover.
2. Install screws of protective cover.
3. Install safety equipment (if fitted).
4. Check function of safety equipment (if fitted).
MS150118/00E 2014-07 | Task Description | 121
TIM-ID: 0000054572 - 001
