7.9.2 Starter – Removal
Preconditions
☑Engine is stopped and starting disabled.
DANGER
Electric voltage supply for operation.
Danger of burns and fatal electric shock!
• Make certain that the power supply to the product is switched off before starting work. Secure
against unintentional switching on!
WARNING
The component is very heavy and may fall or tip over if unstable.
Risk of crushing injuries to persons or limbs!
• Use appropriate lifting gear and equipment.
• Wear safety footwear.
Disconnecting and removing starter
1. Prior to disconnection, mark all cables.
2. Disconnect all cables from starter.
3. Protect all cables from damage.
4. Remove starter nuts as shown in overview drawing (→ Page 96).
5. Remove starter.
6. Protect starter from damage.
MS150118/00E 2014-07 | Task Description | 97
TIM-ID: 0000006063 - 004
