Page #76 background imageLoading...
Page #76 background image
7.4.2 Injector – Removal and installation
Preconditions
Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Press-in tool
F6790085 1
Puller
F6790636 1
Fuel suction device
F30378207 1
Torque wrench, 20-100 Nm
F30026582 1
Torque wrench, 0.5-5 Nm
0015384230 1
Ratchet
F30027340 1
Plug-in open-end wrench, 19 mm
F30453236 1
Crowfoot wrench, 19 mm
F30027424 1
Ring socket, 22 mm
F30038494 1
Double-end box wrench
F30011450 1
Open-end socket wrench, 24 mm
F30453238 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260 1
Engine oil
Sealing ring
(→ Spare Parts Catalog)
WARNING
Fuels are combustible.
Risk of fire and explosion!
Avoid open flames, electrical sparks and ignition sources.
Do not smoke.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
Never direct air jet at people.
Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Shut off fuel supply line.
2. Drain fuel (→ Page 86).
3. Remove cylinder head cover (→ Page 74).
76 | Task Description |
MS150118/00E 2014-07
TIM-ID: 0000050909 - 002
