7.9.3 Starter ‒ Installation
DANGER
Electric voltage supply for operation.
Danger of burns and fatal electric shock!
• Make certain that the power supply to the product is switched off before starting work. Secure
against unintentional switching on!
WARNING
The component is very heavy and may fall or tip over if unstable.
Risk of crushing injuries to persons or limbs!
• Use appropriate lifting gear and equipment.
• Wear safety footwear.
Installing starter
1. Coat starter pinion with lubricating grease.
2. Install starter as shown in overview drawing (→ Page 96).
Starter, electrical connection
1. Connect cables in accordance with the marking.
2. Screw on nuts of connections and use torque wrench to tighten to specified tightening torque.
a) Terminal 30 (battery connection)
Name Size Type Lubricant Value/Standard
Nut M18 Tightening torque 24.7 - 27.5 Nm
b) Terminal 50 (switching connection)
Name Size Type Lubricant Value/Standard
Nut M6 Tightening torque 5 - 7 Nm
c) Terminal 31 (negative terminal)
Name Size Type Lubricant Value/Standard
Nut M6 Tightening torque 13.5 - 15.8 Nm
3. Check starter for correct operation.
98 | Task Description | MS150118/00E 2014-07
TIM-ID: 0000054682 - 001
