MTU 12V2000B26F - Fuel System; HP Fuel Line and Pressure Pipe Connection - Replacement

7.5 Fuel System
7.5.1 HP fuel line and pressure pipe connection ‒ Replacement
Preconditions
☑Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20-100 Nm
F30026582 1
Ratchet
F30027340 1
Plug-in open-end wrench, 19 mm
F30025897 1
Crowfoot wrench, 19 mm
F30027424 1
Ring socket, 24 mm
F30501562 1
Double-end box wrench
F30011450 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260 1
Engine oil
Pressure pipe connection
(→ Spare Parts Catalog)
HP fuel line
(→ Spare Parts Catalog)
Gasket
(→ Spare Parts Catalog)
WARNING
Fuels are combustible.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
Preparatory steps
1. Shut off fuel supply line.
2. Drain fuel (→ Page 86).
3. Remove engine control system (→ Page 129).
4. Remove charge-air pipes and take off seals (only on engines with air-to-charge-air cooling).
5. Remove fuel return line.
