7.2 Crankcase Breather
7.2.1 Crankcase breather – Oil mist fine separator replacement
Preconditions
☑Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Engine oil
Oil mist fine separator
(→ Spare Parts Catalog)
O-ring
(→ Spare Parts Catalog)
WARNING
Hot oil.
Oil can contain combustion residues which are harmful to health.
Risk of injury and poisoning!
• Wear protective clothing, gloves, and goggles / safety mask.
• Avoid contact with skin.
• Do not inhale oil vapor.
Replacing oil mist fine separator
1. Unscrew screws (1) and remove together
with washers (2) and retainer (3).
2. Replace oil mist fine separator (4).
3. Replace O-ring (5) if necessary.
4. Replace further oil mist fine separators in
the same way.
70 | Task Description | MS150118/00E 2014-07
TIM-ID: 0000053449 - 001
