16. Tighten nut (3) to specified tightening torque using a torque wrench.
Name Size Type Lubricant Value/Standard
Nut M16 Tightening torque (Engine oil) 30 Nm +3 Nm
17. Fit gasket (10).
18. Install cover.
19. Install screws (1), washers (2) and nuts (9).
20. Tighten nuts (9).
21. Open ball valve at the inlet and outlet of the fuel treatment system.
Result: The fuel treatment system is ready for operation.
MS150118/00E 2014-07 | Task Description | 127
TIM-ID: 0000007735 - 009
