Consumption
Number of cylinders 12 16
Lube oil consumption after 100 hrs runtime (B = hourly fuel con-
sumption)
% of B 0.8 0.8
Table 51: Consumption
Model-related data (basic design)
Number of cylinders 12 16
Operating method: four-stroke cycle, diesel, single-action X X
Combustion method: direct fuel injection X X
Number of cylinders 12 16
Cylinder arrangement: Vee angle Degrees
(°)
90 90
Bore mm 135 135
Stroke mm 156 156
Displacement of a cylinder Liters 2.233 2.233
Total displacement Liters 26.8 35.7
Compression ratio 17.5 17.5
Standard housing connecting flange (engine main PTO side) SAE 0 0
Table 52: Model-related data (basic design)
Air / exhaust gas
Number of cylinders 12 16
Charge-air pressure before cylinder - DL R bar abs 2.9 2.6
Charge-air pressure before cylinder - BL R bar abs 3.2 2.8
Table 53: Air / exhaust gas
Coolant system (HT circuit)
Number of cylinders 12 16
Coolant temperature (at engine connection: outlet to cooling sys-
tem)
A °C 100 100
Coolant temperature after engine, warning L °C 102 102
Coolant temperature after engine, shutdown L °C 105 105
Coolant antifreeze content, max. L % 50 50
Cooling system: coolant flow rate A m³/h 31.6 41.6
Coolant pump: inlet pressure, min. L bar 0.4 0.4
Coolant pump: inlet pressure, max. L bar 1.5 1.5
Pressure loss in external cooling system outside engine L bar 1.0 1.0
Breather valve (expansion tank) opening pressure at gauge pres-
sure
R bar 1.0 1.0
Cooling system: height above engine, max. L m 20 20
Table 54: Coolant system (HT circuit)
MS150118/00E 2014-07 | Technical Data | 37
TIM-ID: 0000053441 - 001
