Number of cylinders 12 16
Firing speed, from R rpm 100 100
Firing speed. to R rpm 120 120
Table 58: General operating data
Inclined positions, standard oil system (reference: waterline)
Number of cylinders 12 16
Longitudinal inclination, continuous max. driving end bottom (op-
tion: max. operating inclination positions)
L Degrees
(°)
5 5
Longitudinal inclination, continuous max. driving end top (option:
max. operating inclination positions)
L Degrees
(°)
5 5
Transverse inclination continuous max. (design: max. operating in-
clination positions)
L Degrees
(°)
10 10
Table 59: Inclined positions, standard oil system (reference: waterline)
Capacities
Number of cylinders 12 16
Engine coolant capacity, engine side (without cooling system) R Liters 63 70
Charge-air coolant, engine side R Liters - -
Fuel, engine side R Liters 6 6
Engine oil capacity, initial filling (standard oil system) (design:
max. operating inclination positions)
R Liters 92 114
Oil change quantity max. (standard oil system) (design: max. oper-
ating inclination positions)
R Liters 80 102
Table 60: Capacities
Fan / fan cooler
Number of cylinders 12 16
Fan, pusher type X X
Fan drive: mechanical via V-belt X X
Table 61: Fan / fan cooler
Sound
Number of cylinders 12 16
Exhaust noise, not attenuated - DL (free-field sound pressure level
Lp, 1 m distance, ISO 6798, +3 dB(A) tolerance)
R dB(A) 112 119
Exhaust noise, not attenuated - DL (sound power level LW, ISO
6798, +3 dB(A) tolerance)
R dB(A) 125 117
Engine surface noise with attenuated intake noise (filter) - DL
(free-field sound power level Lp, 1 m distance, ISO 6798, +2 dB(A)
tolerance)
R dB(A) 100 -
Engine surface noise with attenuated intake noise (filter) - DL
(sound power level LW, ISO 6798+2 db(A) tolerance)
R dB(A) 117 -
Table 62: Sound
MS150118/00E 2014-07 | Technical Data | 39
TIM-ID: 0000053441 - 001
