Inclined positions, standard oil system (reference: waterline)
Number of cylinders 16
Longitudinal inclination, continuous max. driving end bottom (option: max.
operating inclination positions)
L Degrees (°) 5
Longitudinal inclination, continuous max. driving end top (option: max. op-
erating inclination positions)
L Degrees (°) 5
Transverse inclination continuous max. (design: max. operating inclination
positions)
L Degrees (°) 10
Table 104: Inclined positions, standard oil system (reference: waterline)
Capacities
Number of cylinders 16
Engine coolant capacity, engine side (without cooling system) R Liters 70
Charge-air coolant, engine side R Liters -
Fuel, engine side R Liters 6
Engine oil capacity, initial filling (standard oil system) (design: max. operat-
ing inclination positions)
R Liters 114
Oil change quantity max. (standard oil system) (design: max. operating in-
clination positions)
R Liters 102
Table 105: Capacities
Fan / fan cooler
Number of cylinders 16
Fan, pusher type X
Fan drive: mechanical via V-belt X
Table 106: Fan / fan cooler
Sound
Number of cylinders 16
Exhaust noise, not attenuated - DL (free-field sound pressure level Lp, 1 m
distance, ISO 6798, +3 dB(A) tolerance)
R dB(A) -
Exhaust noise, not attenuated - DL (sound power level LW, ISO 6798,
+3 dB(A) tolerance)
R dB(A) -
Engine surface noise with attenuated intake noise (filter) - DL (free-field
sound power level Lp, 1 m distance, ISO 6798, +2 dB(A) tolerance)
R dB(A) -
Engine surface noise with attenuated intake noise (filter) - DL (sound pow-
er level LW, ISO 6798+2 db(A) tolerance)
R dB(A) -
Table 107: Sound
MS150118/00E 2014-07 | Technical Data | 53
TIM-ID: 0000053444 - 001
