Technical Specifications
Specifications SF 100 SF 400/800
Hardware
Interfaces
Network: 1 Ethernet 10/100BaseT Network: 1 Ethernet 10/100BaseT
Console: 1 serial RS-232
Wireless Modems 1 Quad Band GSM
850/900/1800/1900 MHz
4 or 8 Quad Band GSM
850/900/1800/1900 MHz
Dimensions
6.4” w x 1.2” h x 6” d
(16.3 cm x 3.0 cm x 15.2 cm)
17.4” w x 1.75” h x 8.5” d
(44.2 cm x 4.5 cm x 21.6 cm)
Weight 1.25 lbs.
(.56 kg)
SF 400: 7.75 lbs. (3.52 kg)
SF 800: 8.00 lbs. (3.64 kg)
Operating
Temperature
+32
o
to +120
o
F (0
o
to +50
o
C)
Note: UL listed @ +40
o
C (limited by power supply)
+32
o
to +120
o
F (0
o
to +50
o
C)
Humidity 20–90% non-condensing 20–90% non-condensing
Hardware
Connectors
SIM connector: Standard 3V
Antenna: RF 50 ohm SMA (female)
Network: RJ-45 (female)
SIM connector: Standard 3V
Antenna: RF 50 ohm SMA (female)
Network: RJ-45 (female)
Console: DE9 (female)
Power*
External Power Supply
Input: 100-240Vac, 0.5A 50-60 Hz
Output: 9VDC, 1.7A
Power Consumption
Maximum consumption is 0.95A at 9V
Input 9v Typical Maximum Peak
Current (A) 0.564 0.712 1.600
Watts 5.0 6.2
Input 20v Typical Maximum Peak
Current (A) 0.276 0.330 0.700
Watts 5.5 6.6
Input 32v Typical Maximum Peak
Current (A) 0.191 0.225 0.625
Watts 6.1 7.2
Power Supply – (Universal Input)
Input: 100-240Vac, 1.8 – 1.0 A 50/60 Hz
SF400 / SF800:
Input 120Vac Typical Maximum
Current (Amps) 0.078/0.126 0.105/0.150
Watts 9.20/15.04 12.44/17.94
Input 220Vac Typical Maximum
Current (Amps) 0.068/0.124 0.085/0.140
Watts 14.96/27.30 18.73/30.84
Certifications and
Approvals
CE Mark; R&TTE
EMC Compliance:
FCC Part 15 Class A; EN 55022 Class A;
EN 55024; ACIF S042.1; ACIF S042.3
Radio Compliance:
FCC Part 22, 24
EN 301 489-1; EN 301489-7;
EN 301 511
RSS 132, 133, 102
Safety:
cUL 60950-1; UL 60950-1;
IEC 60950-1; AS/NZS 60950
Network Compliance:
PTCRB, GCF
CE Mark; R&TTE
EMC Compliance:
FCC Part 15 Class A; EN 55022 Class A;
EN 55024; ACIF S042.1; ACIF S042.3
Radio Compliance:
FCC Part 22, 24
EN 301 489-1; EN 301489-7;
EN 301 511
RSS 132, 133, 102
Safety:
cUL 60950-1; UL 60950-1;
IEC 60950-1; AS/NZS 60950
Network Compliance:
PTCRB, GCF
Warranty
2 years
2 years
* Multi-Tech Systems, Inc. recommends that the customer incorporate a 10% buffer into their power source when
determining product load.
