Maintenance Manual – SC Cutting Plotter
103
AP-
74030, Rev / B
9.3. Cover left assy
SC-550.
Ref. Descriptio
n
Partn
umber
Qty
1
Cover
left SC-550
ZME-20555
1
2 Screw
M3x8
DR-
4001-43329
3
3 Screw
3.0x10
BM-2301-503010
6
4 Label
SC-550
LB-
20550
1
102
104
