Maintenance Manual – SC Cutting Plotter
72 AP-74030, Rev / B
6.3.17. Fan motors : removal and installation.
Step 1 : Open the PCB box (Please refer to 6.2.3. PCB box). (Not for SC-550)
Step 2 : Remove the fan motor cable(s) (red, black, brown) from the main PC board.
Step 3 : Remove the fan motors from the X-rail with 2 screws.
Note :
To reinstall the fan motors perform above steps in reversed order.
