Maintenance Manual – SC Cutting Plotter
21 AP-74030, Rev / B
4. TROUBLESHOOTING.
When errors occurring during cutting or after powering on the machine, some LED code may appear on the
LED bar to inform you about the kind of error.
In general 2 different types of error messages may occur :
4.1. Recoverable errors.
Recoverable errors can be recognized by some flashing LED’s on the LED bar. Sometimes the machine
continue to work while LED’s are flashing. Sometimes it stops but continue again after correction of the
error.
Recoverable errors are mostly related to communication problems or user mistakes.
4.1.1. RECOVERABLE SYSTEM ERRORS
ERROR CODE
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
IMPOSSIBLE AUTO-
ON-LINE RECOG (S02)
G. LANGUAGE NOT
CORRESPONDING (S03)
MEDIA DETECT ERROR (S05)
ROLL MEDIA END (S06)
CANNOT AUTO-CONNECT (S07)
AUTO CUT ERROR (S08)
CHANGE MEDIA (S28)
KANJI ROM SUM ERROR (S29)
POSSIBLE CAUSE & SUGGESTED ACTION
S02 Communication difficulties – Check cables.
S03 Select other graphics language. (Chapter 3 - Language Settings )
S05 Media detection impossible.
Too much or too little light, incorrect pressure roll position.
S06 Load a new sheet or roll.
S07 Communication difficulties – Check cables.
S08 Error during auto-sheet-off sequence.
Check media and auto-cut knife.
S28 Change or reload media.
