Maintenance Manual – SC Cutting Plotter
34 AP-74030, Rev / B
Step 7 : When finished power off the machine.
5.2.4. Measuring the CUTTING MAT height.
Caution :
This adjustment routine requires a special tool!
DO NEVER start this routine without this tool.
Step 1 : Place TOOL JD-44140 (adjustment pen) in head.
Step 2 : Power on the unit in diagnostic mode. (No medium loaded)
Step 3 : Press the [ORIGIN] key until 80% LED is on.
Step 4 : Press the [VALUE ] key. (Unit starts initialising, wait until finished)
Step 5 : Press the [VALUE ¯] and [ENTER] key. (Unit starts measuring the cutting mat height on several
places, wait until finished.)
Step 6 : Press the [ENTER] key. (The values are now stored in EEPROM)
Step 7 : Power off.
5.2.5. Adjusting the SHEET OFF system.
(NOT for SC-550)
Step 1 : Power on the unit in diagnostic mode (No medium loaded).
Step 2 : Press the [ORIGIN] key until 90% LED is on.
Step 3 : Press the [VALUE ] (Unit starts initialising, wait until finished).
Step 4 : Press the [VALUE ¯] and [ENTER] key.
The head moves to the left hand side and stops approximately 60 mm before the left hand side of
the machine.
Open the transparent caver and move the head manually to the utmost left position. The correct
position is that the head is at the left as much as possible but that the knife catch bracket is still
free to move UP/DOWN. Check that the head can catch the bracket and hold it firmly.
Step 5 : With the cover still open (!!! IMPORTANT !!!), press the [ENTER] key twice. The value is stored
now in the EEPROM.
Step 6 : After closing the cover, the head will move to the right.
Step 7 : Power off.
