MUTOH SC-650 - SC-550 Y-Motor Assembly Parts

Maintenance Manual – SC Cutting Plotter
109 AP-74030, Rev / B
9.8. Y-MOTOR Assy SC-550.
Ref. Description Partnumber Qty
# Y-motor assy EY-1012 1
1 Y-motor DE-32442 1
2 Drive pulley DE-4707 1
- ---------------------------------------------------------- --------------------------- -
3 Screw M4x10 DR-4001-43317 2
4 Y-reduction belt DE-47079 1
