MUTOH SC-650 - SC-Series X-Motor Assembly Parts

Maintenance Manual – SC Cutting Plotter
84 AP-74030, Rev / B
8.8. X-motor assy.
Ref. Description Partnumber Qty
# X-motor assy EY-10000 1
1 X-motor EE-10000 1
2 Drive pulley DE-46568 1
3 Setscrew DR-4007-43352 2
- ---------------------------------------------------------- --------------------------- -
4 Screw M3x10 DR-4001-43395 2
5 X-drive belt DE-44157 1
