Maintenance Manual – SC Cutting Plotter
33 AP-74030, Rev / B
5.2.2. Aging.
This test makes the plotter continuously moving in the X-/Y- axis.
This test can be performed without media or with media loaded.
Step 1 : Power on the plotter in diagnostics mode.
Step 2 : Press the [ORIGIN] key until 50 % LED is on.
Step 3 : Press the [VALUE ¯] key. (Unit starts initialising, wait until finished)
Step 4 : Press [MENU ] key.
Step 5 : The [NEXT/+] or [LAST/-] key keys will determine what axis is to be aging.
· [MENU ] will continuous move the X and Y axis.
· [VALUE ¯] will continuous move the X axis only.
· VALUE ] will continuous move the Y axis only.
Note :
Press the [VALUE ¯] key to start / pause aging.
Press the [VALUE ] key to end aging and select another axis to be aged if
desired.
Step 6 : Power OFF.
5.2.3. Drawings for quality check.
Step 1 : Power on the unit in Diagnostics mode.
Step 2 : Put a pen in the head and load some paper.
Step 3 : Press the [ORIGIN] key until 50% LED is on.
Step 4 : Press the [VALUE ¯] key (Unit starts initialising and loads medium if lever is down. Wait until
finished)
Step 5 : Press the [VALUE ] key.
Step 6 : The next key will determine the kind of drawing to be made.
· [MENU ¯] for ZIG ZAG test
· [MENU ] for 45° test
· [VALUE ¯] for DASH LINE test
· [VALUE] for circles test
Now you have to position the tool (pen) on the desired place on the medium by using the JOG
keys (arrow keys).
Note :
Press the [VALUE ¯] key to start / pause the test drawing.
Press the [VALUE ] key to end and select another drawing
