Maintenance Manual – SC Cutting Plotter
75 AP-74030, Rev / B
8. PARTS LISTS SC-SERIES.
(For SC-550 parts, please refer to chapter 9. Parts Lists SC-550.)
8.1. Body and Covers.
Ref. Description Partnumber Qty
1 Cover right ZME-20654 1
2 Cover left SC-650 ZME-20665 1
2 Cover left SC-750 ZME-20755 1
2 Cover left SC-1000 ZME-21005 1
2 Cover left SC-1300 ZME-21305 1
3 Transparent cover assy SC-650 MY-20631 1
3 Transparent cover assy SC-750 MY-20731 1
3 Transparent cover assy SC-1000 MY-21630 1
3 Transparent cover assy SC-1300 MY-21252 1
4 Front platen assy SC-650 MY-20602 1
4 Front platen assy SC-750 MY-20702 1
4 Front platen assy SC-1000 MY-21602 1
4 Front platen assy SC-1300 MY-21250 1
