Maintenance Manual – SC Cutting Plotter
76 AP-74030, Rev / B
5 Grid cover SC-650 ME-20650 1
5 Grid cover SC-750 ME-20750 1
5 Grid cover SC-1000 ME-21650 1
5 Grid cover SC-1300 ME-21251 1
6 Rear platen SC-650 ME-20602 1
6 Rear platen SC-750 ME-20702 1
6 Rear platen SC-1000 ME-21602 1
6 Rear platen SC-1300 ME-21250 1
7 Y-rail cover SC-650 ME-20630 1
7 Y-rail cover SC-750 ME-20730 1
7 Y-rail cover SC-1000 ME-21630 1
7 Y-rail cover SC-1300 ME-21612 1
7’ Screw 2.9 X 9.5 BM-2102-129905 4
8 Head cover ME-20662 1
8’ Screw M2x4 DR-4004-45105 1
8” Screw M2x10 DR-4004-45100 1
9 Side plate left ME-20599 1
10 Side plate right ME-20600 1
11 Cover switch assy EY-41761 1
11’ Screw M2x8 BM-1400-002008 2
12 Rubber BR-40040 2
12’ Screw M4x6 black DR-4008-41838 2
13 Alignment sticker LB-10017 2
14 Sheet off knock piece ME-20640 1
14’ Screw M4x6 black DR-4008-41838 1
15 Conveyor roll SC-650 ME-20610 2
15 Conveyor roll SC-750 ME-20710 2
15 Conveyor roll SC-1000 ME-21610 2
15 Conveyor roll SC-1300 ME-21710 2
16 Roll flange assy MY-10056 2
17 Slip-ring ME-20700 1
18 Hex bolt M4x6 BM-6000-604008 1
18’ Plastic spacer (d = 4.2) BR-40108 1
19 Hex bolt M8x25 BM-6200-608025 2
19’ Brass spacer BR-10845 2
19” Plastic plain washer BR-40842 4
20 Hex bolt M8x20 BM-6200-608020 2
20’ Plastic spacer (d = 8.2) BR-40812 1
21 Bottom cover left ME-20652 1
22 Bottom cover right ME-20656 1
