MUTOH SC-650 - Page 105

Maintenance Manual – SC Cutting Plotter
105 AP-74030, Rev / B
PCB box right parts list
Ref. Description Partnumber Qty
1 Right PCB box ME-20556 1
2 Main PCB SC-550 1
st
version EY-22570 1
2 Main PCB SC-550 2
nd
version EY-23570 1
3 Terminal PCB SC 1
st
version EY-20573 1
3 Terminal PCB SC 2
nd
version EY-21573S 1
4 Power ON/OFF switch DE-43074 1
5 Power inlet DE-44745 1
6 Head FCC cable MK-60867 1
7
Cable j102 ® J515
MK-60865 1
8
Cable J113 ® J500 1
st
version
MK-60627 1
8
Cable J130 ® J500 2
nd
version
MK-41200 1
9
Cable J101 ® J512 1
st
version
MK-60864 1
10
Cable P/S ® mainboard
MK-51550 1
11
Cable switch ® P/S
MK-81550 1
12 Extens. Cable X-encoder MK-41500 1
13 Extens. Cable Y-encoder MK-41501 1
14 Bracket Terminal board ME-20508 2
15 Plate cover right ME-20658 1
16 Screw M3x4 DR-4001-43993 3
17 Screw M3x25 DR-4005-44614 1
18 Screw M3x6 DR-4001-43923 14
19 Screw M3x10 (Interf.) DR-4007-44129 2
20 Screw hex M3x8 BM-6301-603008 5
21 Rubber floot BR-40040 2
22 Screw hex M4x8 BM-6200-604008 2
23 Cable bracket ME-20634 1
24 Cable guide AE-91025 7
24’ Cable guide AE-92788N 1
PCB box left parts list.
Ref. Description Partnumber Qty
1 Left PCB box ME-20552 1
2 Power supply board DE-31396 1
3 Bracket P/S left ME-20510L 1
4 Bracket P/S right ME-20510R 1
5 Screw M3x6 DR-4001-43923 5
5 Screw M3x4 DR-4001-43993 4
6 Rubber foot BR-40040 2
7 Screw hex M4x8 BM-6200-604008 2
8 Screw hex M3x8 BM-6301-603008 5
