MUTOH SC-650 - Page 86

Maintenance Manual – SC Cutting Plotter
86 AP-74030, Rev / B
15 Cutting mat SC-650 ZME-20645 3
15 Cutting mat SC-750 ZME-20745 3
15 Cutting mat SC-1000 ZME-21645 3
15 Cutting mat SC-1300 ZME-21745 3
16 Screw M2x5 BM-6301-302005 7-7-10
-- ---------------------------------------------------------- --------------------------- -
17 Fan 650, 750, 1000, 1300 EE-50760 1
17 Fan SC-1000, 1300 EE-50761 1
17 Fan SC-1300 DE-44761 1
17’ Screw 3.5x32 BM-2100-135032 2-4
18 Gear grid shaft DE-46555 1
18’ Set screw M3x3 DR-4007-43352 2
19 Bearing grid shaft DE-46563 1
19’ Screw M3x4 DR-4001-43993 2
