List of specifications 95
List of specifications
Model name VJ-628MP
Print method On demand piezo method
Drive method Firmware servo/DC motor drive
Paper feed method Horizontal conveyance, roll paper, set from the back of the
product, front discharge paper with paper feed operation,
limited to outward roll
Media fix Pressure roller down method with manual media fixing knob
Conditions of usable
media
Roll paper peripheral 150 mm
Roll paper weight 9 kg or less
Maximum paper width 630 mm (In case of paper tube > paper width, paper tube
width)
Maximum paper thickness Head height when set to “Low”: 0.3 mm Max.
Head height when set to “High”: 1.3 mm Max.
Maximum print width 620 mm
Media cut method Auto cut or manual cut
Heater Installed under the media guide, OFF/30 °C to 45 °C
Head height
adjustment
2 levels, Low and High
CPU 64 bit RISC CPU
Memory 256 MB
Interface Ethernet (10/100BASE-TX)
Ink Color 4 colors (Black, Cyan, Magenta, Yellow)
5 colors (Black, Cyan, Magenta, Yellow, White)
Type 220 ml ink cartridge (Black, Cyan, Magenta, Yellow, White)
Waste ink tank Fixed to the leg, capacity 2,000 ml, waste ink discharge by users
Environmental
conditions
Operating environment Temperature 20 to 32 °C, humidity 40 to 60%, (Non-
condensing)
Recommended Printing
Environment
Temperature 22 to 30 °C, humidity 40 to 60%, (Non-
condensing)
Change rate Temperature: No more than 2 °C per 1 hour
Humidity: No more than 5% per 1 hour (Non-condensing)
Environment for storage • Storage without ink charging: up to 6 months
Temperature -20 to +60 °C, humidity 20 to 80% (Non-
condensing)
• Storage with ink charging: up to 30 days
(Perform the Daily Maintenance in the operation manual)
Temperature: 5 to 30 °C, humidity: 20 to 80% (Non-
condensing)
