CS USER REPORTING CODES (ADDRESS 1030-1080)
NOTE: These opening events will report as the user
number shown. Also, Keyfobs 1-16 (see Easy Menu
Program Driven Mode) will report as Users 180-195,
respectively.
CS USER REPORTING CODES
USERS 1 8
USERS 9 16
ADDR U1 U2 U3 U4 U5 U6 U7 U8 ADDR U9 U10 U11 U12 U13 U14 U15 U16
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
User Opening Telco 1
1030
1031
User Closing Telco 1
1043
1044
User Opening Telco 3
1056
1057
User Closing Telco 3
1069
1070
Enable Users to Report
USERS 17 24
USERS 25 32
ADDR U17 U18 U19
U20
4
U21 U22 U23 U24 ADDR U25 U26 U27 U28 U29 U30 U31 U32
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
User Opening Telco 1
1032
1033
User Closing Telco 1
1045
1046
User Opening Telco 3
1058
1059
User Closing Telco 3
1071
1072
Enable Users to Report
USERS 33 40
USERS 41 48
ADDR U33 U34 U35 U36 U37 U38 U39 U40 ADDR U41 U42 U43 U44 U45 U46 U47 U48
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
User Opening Telco 1
1034
1035
User Closing Telco 1
1047
1048
User Opening Telco 3
1060
1061
User Closing Telco 3
1073
1074
Enable Users to Report
USERS 49 56
USERS 57 64
ADDR U49 U50 U51 U52 U52 U54 U55 U56 ADDR U57 U58 U59 U60 U61 U62 U63 U64
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
User Opening Telco 1
1036
1037
User Closing Telco 1
1049
1050
User Opening Telco 3
1062
1063
User Closing Telco 3
1075
1076
Enable Users to Report
USERS 65 72
USERS 73 80
ADDR
U65 U66 U67 U68 U68 U70 U71 U72
ADDR
U73 U74 U75 U76 U77 U78 U79 U80
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
User Opening Telco 1
1038
1039
User Closing Telco 1
1051
1052
User Opening Telco 3
1064
1065
User Closing Telco 3
1077
1078
Enable Users to Report
USERS 81 88
USERS 89 96
ADDR U81 U82 U83 U84 U85 U86 U87 U88 ADDR U89 U90 U91 U92 U93 U94 U95 U96
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
User Opening Telco 1
1040
1041
User Closing Telco 1
1053
1054
User Opening Telco 3
1066
1067
User Closing Telco 3
1079
1080
Enable Users to Report
To Next Page
