L NAPCO Security Systems
X GEM-X255 Programming Instructions

Page 29
WI1092E 10/05
AREA SYSTEM TROUBLE REPORTING OPTIONS
AREA SYSTEM TROUBLE REPORTING OPTIONS (ADDRESS 1120-1157)
 1. Select the desired option entering the option number (1-8) for each digit.
 2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available.
 3. Press U or D to save.
SYSTEM RESPONSE
ACTIVATED BY AREA 1
EVENT/TROUBLE
AREA 1 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1120
Default ON
Burglary Output 1121
Default ON Default ON
Fire Output (Lug E9) 1122
Reset Relay 1123
Auxiliary Relay 1124
Report Alarm Telco 1 1125
Report Alarm Telco 3 1127
Defaults as noted from address 1120-1127]
SYSTEM RESPONSE
ACTIVATED BY AREA 2
EVENT/TROUBLE
AREA 2 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1130
Default ON
Burglary Output 1131
Default ON Default ON
Fire Output (Lug E9) 1132
Reset Relay 1133
Auxiliary Relay 1134
Report Alarm Telco 1 1135
Default ON Default ON Default ON
Report Alarm Telco 3 1137
[Defaults as noted from address 1130-1137]
SYSTEM RESPONSE
ACTIVATED BY AREA 3
EVENT/TROUBLE
AREA 3 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1140
Burglary Output 1141
Fire Output (Lug E9) 1142
Reset Relay 1143
Auxiliary Relay 1144
Report Alarm Telco 1 1145
Report Alarm Telco 3 1147
[Default = blank (•) blank (•) from address 1140-1147]
SYSTEM RESPONSE
ACTIVATED BY AREA 4
EVENT/TROUBLE
AREA 4 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1150
Burglary Output 1151
Fire Output (Lug E9) 1152
Reset Relay 1153
Auxiliary Relay 1154
Report Alarm Telco 1 1155
Report Alarm Telco 3 1157
[Default = blank (•) blank (•) from address 1150-1157]
