X GEM-X255 Programming Instructions
L NAPCO Security Systems
Page 8
WI1092E 10/05
GEM-RP1CAE2/GEM-K1CA KEYPAD EASY PROGRAM MENU
Enable SIA CP-01 Features?
• Press the NEXT/YES button to enable.
• Press the PRIOR/NO button to continue.
The SIA CP-01 Features are designed to reduce the incidence of false alarms.
NOTE: Do not enable
unless reporting, otherwise system trouble Fail to Communicate may occur.
Number of Keypads in Area 1
• Enter the total number of Keypads to be installed in Area 1.
• Valid entries are from 01 to 15. Directly enter the number of keypads, including leading zeros.
Press
U to save. Press the NEXT/YES button to proceed.
Number of Keypads in Area 2
• Enter the total number of Keypads to be installed in Area 2.
• Valid entries are from 00 to 15. Directly enter the number of keypads, including leading zeros.
Press
U to save. Press the NEXT/YES button to proceed. NOTE: Area 2 keypads must have zones in
Area 2, otherwise the keypad will indicate "Out Of System".
Central Station Receiver 1 Telephone Number
• Enter telephone number of up to 16 digits.
• Press 1 through 9 for digits 1–9; G 0 for a zero and 0 for a blank (•).
• Press G 1 through G 5 for letters B–F, respectively.
• Pre-Dial Delay = “D” (G 4); Dial-Tone Detection = “E” (G 5).
• Press U to save and press the NEXT/YES button to proceed.
NOTE: Central Station Receiver 2 and 3 Telephone Numbers must be entered in Direct Address Program-
ming. See CS Receiver Options.
(Direct Entry)
Central Phone #
(Direct Entry)
# Area 1 Keypads
Enter # KPs 01
(Press YES or NO)
Enable SIA CP-01?
Y/N
(Direct Entry)
# Area 2 Keypads
Enter # KPs 00
Easy Programming of Auto download ID #'s and PC Preset Callback Numbers (GEM-RP1CAe2 or GEM-K1CA
keypads only) from the Central Station Telephone number.
For unattended PC Preset downloading, it is now possible to set the Auto download ID #’s and PC Preset Callback
from the Keypad Easy Program Mode.
• At the field for CENTRAL PHONE #, program an "F" followed by the Auto Download ID # (2 digits) and then the
Callback Telco # (up to 13 digits).
• Press D or U to save.
• Exit Program Mode (CC)
• Enter Master Code
• Press A or R
• Go to Function "ACTIVATE DOWNLOAD Y/N" and press YES (E or P).
• The panel will automatically call the PC Preset computer and download the program on the specified Auto
Download line # of PC Preset. Example: Program an Auto download ID # of 07 and a PC Preset Callback # of
1-516-842-9400
• Go to Central Phone # input screen and press: [*] [5] [0] [7] [1] [5] [1] [6] [8] [4] [2] [9] [4] [0] [0]
D (or U).
CENTRAL PHONE #
F0715168429400
