L NAPCO Security Systems
X GEM-X255 Programming Instructions

Page 49
WI1092E 10/05
AREA OUTPUT CONTROL OPTIONS (ADDRESS 2700-2739)
AREA OUTPUT TURNS OFF UPON DISARM: Select options for any of the 5 Outputs per area when disarming a particular area.
 1. Select the desired option.
 2. Enter the corresponding Area number in each the address location, in Binary (Bit) Format. NOTE: See Direct Address
Programming Example on page 15.
 3. Press U or D to save.
AREA OUTPUT CONTROL
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 5 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2704
Pulsed Burg. Output 2712
Fire Output 2720
Reset Relay 2728
Auxiliary Relay 2736
[Default = blank (•) blank (•) from address 2704-2737]
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 6 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2705
Pulsed Burg. Output 2713
Fire Output 2721
Reset Relay 2729
Auxiliary Relay 2737
[Default = blank (•) blank (•) from address 2704-2737]
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 1 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2700 ON ON
Pulsed Burg. Output 2708 ON ON
Fire Output 2716
Reset Relay 2724
Auxiliary Relay 2732
[Default = Noted above with "ON"]
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 2 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2701 ON ON
Pulsed Burg. Output 2709 ON ON
Fire Output 2717
Reset Relay 2725
Auxiliary Relay 2733
[Default = Noted above with "ON"]
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 3 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2702
Pulsed Burg. Output 2710
Fire Output 2718
Reset Relay 2726
Auxiliary Relay 2734
[Default = blank (•) blank (•) from address 2702-2735]
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 4 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2703
Pulsed Burg. Output 2711
Fire Output 2719
Reset Relay 2727
Auxiliary Relay 2735
[Default = blank (•) blank (•) from address 2702-2735]
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 7 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output 2706
Pulsed Burg. Output 2714
Fire Output 2722
Reset Relay 2730
Auxiliary Relay 2738
OUTPUT SILENCED
(TURNED OFF)
DISARMING AREA 8 TURNS OFF AREA OUTPUT
ADDR A1 A2 A3 A4 A5 A6 A7 A8
1 2 3 4 5 6 7 8
Burglary Output
2707
Pulsed Burg. Output 2715
Fire Output 2723
Reset Relay 2731
Auxiliary Relay 2739
