X GEM-X255 Programming Instructions
L NAPCO Security Systems

Page 30
WI1092E 10/05
AREA SYSTEM TROUBLE REPORTING OPTIONS (ADDRESS 1160-1197)
AREA SYSTEM TROUBLE REPORTING OPTIONS
SYSTEM RESPONSE
ACTIVATED BY AREA 8
EVENT/TROUBLE
AREA 8 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1190
Burglary Output 1191
Fire Output (Lug E9) 1192
Reset Relay 1193
Auxiliary Relay 1194
Report Alarm Telco 1 1195
Report Alarm Telco 3 1197
[Default = blank (•) blank (•) from address 1180-1187]
SYSTEM RESPONSE
ACTIVATED BY AREA 5
EVENT/TROUBLE
AREA 5 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1160
Burglary Output 1161
Fire Output (Lug E9) 1162
Reset Relay 1163
Auxiliary Relay 1164
Report Alarm Telco 1 1165
Report Alarm Telco 3 1167
[Default = blank (•) blank (•) from address 1160-1167]
SYSTEM RESPONSE
ACTIVATED BY AREA 6
EVENT/TROUBLE
AREA 6 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output
1170
Burglary Output 1171
Fire Output (Lug E9) 1172
Reset Relay 1173
Auxiliary Relay 1174
Report Alarm Telco 1 1175
Report Alarm Telco 3 1177
[Default = blank (•) blank (•) from address 1170-1177]
SYSTEM RESPONSE
ACTIVATED BY AREA 7
EVENT/TROUBLE
AREA 7 SYSTEM EVENT/TROUBLE
ADDR
AMBUSH
KEYPAD
PANIC
KEYPAD
FIRE
KEYPAD
AUX.
KEYPAD
TAMPER
FAIL TO
OPEN
FAIL TO
CLOSE
RSRVD.
1 2 3 4 5 6 7 8
Pulsed Burg. Output 1180
Burglary Output 1181
Fire Output (Lug E9) 1182
Reset Relay 1183
Auxiliary Relay 1184
Report Alarm Telco 1 1185
Report Alarm Telco 3 1187
[Default = blank (•) blank (•) from address 1180-1187]
 1. Select the desired option entering the option number (1-8) for each digit.
 2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available.
 3. Press U or D to save.
