X GEM-X255 Programming Instructions

Page 35
WI1092E 10/05
ZONE OPTIONS / ZONES 65-80 (ADDRESS 2002-2186)
ZONE OPTIONS / ZONES 65-80
ZONES 65  72 ZONES 73  80
ZONE OPTIONS ADDR Z65 Z66 Z67 Z68 Z69 Z70 Z71 Z72 ADDR Z73 Z74 Z75 Z76 Z77 Z78 Z79 Z80
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8

Priority 2002 2102
Priority with Bypass 2003 2103
Auto-Bypass 2004 2104

Selective Bypass 2005 2105
Keyswitch Arming 2006 2106
Auto-Bypass Re-entry 2007 2107
Pre-Alarm Warning 2008 2108
Never Arm 2009 2109
24-Hour Zone 2010 2110

Burg. Alarm Output 2011 2111

Pulsed Alarm Output 2012 2112
Fire Output (Lug E9) 2013 2113
Reset Relay 2014 2114
Auxiliary Relay 2015 2115
Entry/Exit 1 2016 2116
Entry/Exit 2 2017 2117
Exit/Entry Follower 2018 2118
 
Auto Reset 2019 2119
 
Swinger Shutdown 2020 2120
Chime 2021 2121
Abort Delay 2022 2122
Power-up Delay 2023 2123
Day Zone Open 2024 2124
Day Zone Short 2025 2125
Alarm on Day Zone 2026 2126
RPT Alarm Tel 1 2027 2127
RPT Alarm Restore Tel 1 2028 2128
RPT Trouble Tel 1 2029 2129
RPT Trouble Restore Tel 1 2030 2130
RPT Alarm Tel 3 2035 2135
RPT Alarm Restore Tel 3 2036 2136
RPT Trouble Tel 3 2037 2137
RPT Trouble Restore Tel 3 2038 2138
No EOL Resistor 2039 2139
Sensor Watch 2040 2140
Trouble on Open 2041 2141
Trouble on Short 2042 2142
Trouble on Night Open 2043 2143
Zone Area 1 2044 2144
Zone Area 2 2045 2145
Zone Area 3 2046 2146
Zone Area 4 2047 2147
Zone Area 5 2048 2148
Zone Area 6 2049 2149
Zone Area 7 2050 2150
Zone Area 8 2051 2151
Guard Tour Bypass 2053 2153
Zone ANDing Group 1 2054 2154
Zone ANDing Group 2 2055 2155
Zone ANDing Group 3 2056 2156
Zone ANDing Group 4 2057 2157
Zone ANDing Group 5 2058 2158
Zone ANDing Group 6 2059 2159
Zone ANDing Group 7 2060 2160
Zone ANDing Group 8 2061 2161
Interior #1 Bypass 2062 2162

Interior #2 Bypass 2063 2163
Keypad Sounder on Alarm 2064 2164
Fire (C) 2075 2175
Fire Alarm Verification (C) 2076 2176
Chime 2
2086 2186
 When the Easy Program Menu is used, these features are enabled by default (for new panels or after a Cold Start (address 4093)).
 Do not program if "K Series" keypads (with "
P" and "Q" buttons) are used in the system.
 Disable Auto-Reset on non-fire zones for SIA CP-01 installations.
Interior (STAY) Bypass 2084 2184
See Zone Options on Page 37.
