NAPCO x255 - Zone Options for Zones 81-96; Zone Option Categories Overview

X GEM-X255 Programming Instructions
L NAPCO Security Systems

Page 36
WI1092E 10/05
ZONES 81  88 ZONES 89  96
ZONE OPTIONS ADDR Z81 Z82 Z83 Z84 Z85 Z86 Z87 Z88 ADDR Z89 Z90 Z91 Z92 Z93 Z94 Z95 Z96
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8

Priority 2202 2302
Priority with Bypass 2203 2303
Auto-Bypass 2204 2304

Selective Bypass 2205 2305
Keyswitch Arming 2206 2306
Auto-Bypass Re-entry 2207 2307
Pre-Alarm Warning 2208 2308
Never Arm 2209 2309
24-Hour Zone 2210 2310

Burg. Alarm Output 2211 2311

Pulsed Alarm Output 2212 2312
Fire Output (Lug E9) 2213 2313
Reset Relay 2214 2314
Auxiliary Relay 2215 2315
Entry/Exit 1 2216 2316
Entry/Exit 2 2217 2317
Exit/Entry Follower 2218 2318
 
Auto Reset 2219 2319
 
Swinger Shutdown 2220 2320
Chime 2221 2321
Abort Delay 2222 2322
Power-up Delay 2223 2323
Day Zone Open 2224 2324
Day Zone Short 2225 2325
Alarm on Day Zone 2226 2326
RPT Alarm Tel 1 2227 2327
RPT Alarm Restore Tel 1 2228 2328
RPT Trouble Tel 1 2229 2329
RPT Trouble Restore Tel 1 2230 2330
RPT Alarm Tel 3 2235 2335
RPT Alarm Restore Tel 3 2236 2336
RPT Trouble Tel 3 2237 2337
RPT Trouble Restore Tel 3 2238 2338
No EOL Resistor 2239 2339
Sensor Watch 2240 2340
Trouble on Open 2241 2341
Trouble on Short 2242 2342
Trouble on Night Open 2243 2343
Zone Area 1 2244 2344
Zone Area 2 2245 2345
Zone Area 3 2246 2346
Zone Area 4 2247 2347
Zone Area 5 2248 2348
Zone Area 6 2249 2349
Zone Area 7 2250 2350
Zone Area 8 2251 2351
Guard Tour Bypass 2253 2353
Zone ANDing Group 1 2254 2354
Zone ANDing Group 2 2255 2355
Zone ANDing Group 3 2256 2356
Zone ANDing Group 4 2257 2357
Zone ANDing Group 5 2258 2358
Zone ANDing Group 6 2259 2359
Zone ANDing Group 7 2260 2360
Zone ANDing Group 8 2261 2361
Interior #1 Bypass 2262 2362

Interior #2 Bypass 2263 2363
Keypad Sounder on Alarm 2264 2364
Fire (C) 2275 2375
Fire Alarm Verification (C) 2276 2376
Chime 2
2286 2386
 When the Easy Program Menu is used, these features are enabled by default (for new panels or after a Cold Start (address 4093)).
 Do not program if "K Series" keypads (with "
P" and "Q" buttons) are used in the system.
 Disable Auto-Reset on non-fire zones for SIA CP-01 installations.
Interior (STAY) Bypass 2284 2384
ZONE OPTIONS / ZONES 81-96 (ADDRESS 2202-2386)
ZONE OPTIONS / ZONES 81-96
See Zone Options on Page 37.
