Program 15 : Extension, Basic Setup
15-13 : Loop Keys
Level
IN
Description
Use Program 15-13 : Loop Keys to assign the Loop Key data for each keyset terminal. Loop Keys
can be incoming, outgoing or both ways. Outgoing Loop Keys use the entry in item 1. Incoming Loop
Keys use the entry in item 2. Both Way Loop Keys follow the entries in both item 1 and 2.
Input Data
Extension Number Maximum four digits
Key Number 01 ~ 24
Item No. Item Input Data Default
01 Outgoing Option 0~25
(0 = Assigns the Loop Key for ARS, 1 ~
25 = Assigns the Loop Key to the trunk
group specified)
0
(Programming Function
Key No. 01 ~ 24)
02 Incoming Option 0~25
(0 = Assigns the Loop Key to all trunk
groups,
1 ~ 25 = Assigns the Loop key to the
trunk group specified)
0
(Programming Function
Key No. 01 ~ 24)
Conditions
• Please set Loop Key at Program 15-07 before setting Program 15-13.
Feature Cross Reference
None
ISSUE 1.1SL1000
Program
15
Program 15 : Extension, Basic Setup2-140
