NEC SL100 - Virtual Loop Back Port Setting

Program 10 : System Configuration Setup
10-42 : Virtual Loop Back Port Setting
Level
IN
Description
Use Program 10-42 : Virtual Loop Back Port Setting to set the data for the Virtual Loop Back Port.
Input Data
Item No. Item Input Data Default
01 Number of Loop Back Ports 0~30(0=Nosetting) 0
02 Logical Trunk Port Number 1 ~ 126 0
03 Logical Station Port Number 1 ~ 128 0
04 Layer 3 Timer Type 1~5 1
05 Calling Party Number 0=No
1=Yes
1
06 S-point DDI digits 0~4 0
07 Call Busy Mode for S-point 0 = Alerting Message
1 = Disconnect Message
0
Conditions
None
Feature Cross Reference
None
ISSUE 1.1 SL1000
Program
10
Programming Manual 2-41
