NEC SL100 - Call Progress Tone Detector Setup

Program 80 : Basic Hardware Setup for System
80-04 : Call Progress Tone Detector Setup
Level
IN
Description
Use Program 80-04 : Call Progress Tone Detector Setup to define the various levels and timers for
the Call Progress Tone Detector.
Tone Detector Type :
• 1 = Dial Tone for Trunk
• 2 = Busy Tone for Trunk
• 3 = Ring Back Tone for Trunk
• 4, 5 = Reserved
Input Data
Tone Detector Type Number 1 = Dial Tone for Trunk
2 = Busy Tone for Trunk
3 = Ring Back Tone for Trunk
4 = --- Reserved ---
5 = --- Reserved ---
Item No Item Input Data
01 Detection Level 0=0dBm~-25dBm
1=-5dBm~-30dBm
2=-10dBm~-35dBm
3=-15dBm~-40dBm
4=-20dBm~-45dBm
5=-25dBm~-50dBm
6=-30dBm~-55dBm
02 Min. Detection Level 0~15
0=-10dBm(0)~-25dBm(15)
1=-15dBm(0)~-30dBm(15)
2=-20dBm(0)~-35dBm(15)
3=-25dBm(0)~-40dBm(15)
4=-30dBm(0)~-45dBm(15)
5=-35dBm(0)~-50dBm(15)
6=-40dBm(0)~-55dBm(15)
03 S/N Ratio 0~4(0dB~-20dB)
04 No Tone Time 0 ~ 255 (30 + 30 ~ 7680 ms)
(0 = not detect)
1 ~ 255 = 60 ~ 7680 ms
The formula is 30 + 30N
When set toN=1,itmeans 30 + 30
*
1 = 60.
When set to N = 255, it means 30 + 30
*
255 =
7680.
05 Pulse Count 1 ~ 255
06 ON Minimum Time 1 ~ 255 (30 + 30 ~ 7680 ms)
07 ON Maximum Time 0 ~ 255 (30 + 30 ~ 7680 ms)
08 OFF Minimum Time 1 ~ 255 (30 + 30 ~ 7680 ms)
09 OFF Maximum Time 0 ~ 255 (30 + 30 ~ 7680 ms)
12 Frequency No. 1 1~8
(Frequency Table No. set by 80-07)
13 Frequency No. 2 0~8(0=NotUsed)
(Frequency Table No. set by 80-07)
ISSUE 1.1 SL1000
Program
80
Programming Manual 2-415
