Program 44 : ARS/F-Route Setup
44-05 : ARS/F-Route Table
Level
IN
Description
Use Program 44-05 : ARS/F-Route Table to set the ARS/F-Route table. There are four kinds of order.
If the higher priority trunk groups are busy, the next order group is used. If a lower priority route is se-
lected, the caller may be notified with a beep tone.
Input Data
ARS/F-Route Table Number 001 ~ 100
Priority Number 1 ~ 4
Item No. Item Input Data Default
01 Trunk Group Number
Select the trunk group number to use for the outgoing
ARS call.
0 = No setting
1 ~ 25 = Trunk Group
255 = Extension Call
0
02 Delete Digits
Enter the number of digits to be deleted from the dialed
number.
0 ~ 255
(255 = Delete All)
0
03 Additional Dial Number Table
Enter the table number (defined in Program 44-06) for
additional digits to be dialed.
0 ~ 100 0
04 Beep Tone
Select whether or not a beep is heard if a lower priority
trunk group is used to dial out.
0=Off
1=On
0
05 Gain Table Number for Internal Calls
Select the gain table number to use for the internal call
(defined in Program 44-07).
0 ~ 100
0 = No setting
0
06 Gain Table Number for Tandem Connections
Select the gain table number to use for the tandem call
(defined in Program 44-07).
0 ~ 100
0 = No setting
0
07 ARS Class of Service
Select the ARS Class of Service to use for the table.
An extension ARS COS is determined in Program 26-
04-01.
0~16 0
08 Dial Treatment
Select the Dial Treatment to use for the table. If a Dial
Treatment is selected, Programs 44-05-02 and 44-
05-03 are ignored and the Dial Treatment defined in
Program 26-03-01 is used instead.
0~15 0
09 Maximum Digit
Input the maximum number of digits to send when
using the F-Route.
0~24 0
11 Network Specified Parameter Table
Enter a table number from Program 26-12.
0~16 0
Conditions
None
ISSUE 1.1 SL1000
Program
44
Programming Manual 2-357
