Basic Tone No. Frequency (Hz) Level (dB)
18 650 / 780 -13 / -19
19 780 / 1040 -13 / -19
20 1040 -13
21 450 -13
22 950 -13
23 1800 -13
24 400 / 450 -13/-13
25 400 - 13
26 350 / 440 - 13/- 13
27 420 (Amplitude Modulated) - 13
28 -- Reserve -- -
29 -- Reserve -- -
30 -- Reserve -- -
31 -- Reserve -- -
32 -- Reserve -- -
Default
Ser-
vice
Tone
No.
Service Tone Name
Repeat
Count
Unit Count
Basic Tone
No.
Duration Gain Level (dB)
1 No tone 0 1 0 10 32 (0 dB)
2 Internal Dial Tone 0 1 1 10 42 (+ 5 dB)
3 Stutter Dial Tone
(Special Dial Tone)
0 1 24 10 35 (+ 1.5 dB)
4 Internal Recall Dial Tone
(Transfer Dial Tone)
0 1 24 10 35 (+ 1.5 dB)
5 Trunk Dial Tone 0 4 21
0
21
0
6
10
2
2
45 (0 dB)
45 (0 dB)
45 (0 dB)
45 (0 dB)
6 Internal Busy Tone
(Busy Tone)
02 1
0
5
5
42 (+ 5 dB)
42 (+ 5 dB)
7 DND Busy Tone 0 2 1
0
2
2
42 (+ 5 dB)
42 (+ 5 dB)
8 B-busy Tone 0 2 1
0
5
5
42 (+ 5 dB)
42 (+ 5 dB)
9 Internal Reorder Tone
(Congestion Tone)
02 1
0
2
2
42 (+ 5 dB)
42 (+ 5 dB)
10 Internal Interrupt Tone
(Warning Tone)
02 1
0
2
2
42 (+ 5 dB)
42 (+ 5 dB)
11 Internal Confirmation Tone
(Confirmation Tone)
12 0
1
5
1
42 (+ 5 dB)
42 (+ 5 dB)
12 Internal Hold Tone 0 0 0 0 32 (0 dB)
13 External Hold Tone 0 0 0 0 32 (0 dB)
14 Internal Ring-back Tone
(Internal Audible Ring)
(Ring Back Tone)
02 1
0
10
40
42 (+ 5 dB)
42 (+ 5 dB)
