Item Name Input Data Default
69 Guard Time 1 (DID) 1 ~ 255 (100 ms ~ 25500 ms) 9 (900 ms)
70 Guard Time 1 (E&M) 1 ~ 255 (100 ms ~ 25500 ms) 9 (900 ms)
71 Guard Time 1 (OPX) 1 ~ 255 (100 ms ~ 25500 ms) 9 (900 ms)
72 Guard Time 2 (ALL) 1 ~ 250 (4 ms ~ 1000 ms) 3 (12 ms)
73 Dial Sending Complete Time 1 ~ 255 (100 ms ~ 25500 ms) 20 (2000 ms)
74 ON-HOOK bit Send Time 1 ~ 255 (100 ms ~ 25500 ms) 40 (4000 ms)
75 Open Loop Time (LOOP) 1 ~ 255 (100 ms ~ 25500 ms) 6 (600 ms)
76 Open Loop Time (GROUND) 1 ~ 255 (100 ms ~ 25500 ms) 6 (600 ms)
77 Open Loop Time (DID) 1 ~ 255 (100 ms ~ 25500 ms) 6 (600 ms)
78 Open Loop Time (E&M) 1 ~ 255 (100 ms ~ 25500 ms) 6 (600 ms)
79 Open Loop Time (OPX) 1 ~ 255 (100 ms ~ 25500 ms) 6 (600 ms)
80 Close Loop Time (LOOP) 1 ~ 250 (4 ms ~ 1000 ms) 13 (52 ms)
81 Close Loop Time (DID) 1 ~ 250 (4 ms ~ 1000 ms) 13 (52 ms)
82 Ring GND Time (GROUND) 1 ~ 250 (4 ms ~ 1000 ms) 13 (52 ms)
Conditions
None
Feature Cross Reference
None
ISSUE 1.1 SL1000
Program
81
Programming Manual 2-435
