Item No. Item Input Data Default
45 High-speed Signal Data (FAX Pro-
cedure Signal)
0~2 0
46 TCF Operation Setting 1 = Training signal (TCF) of the fax is locally gener-
ated and checked.
2 = Training signal (TCF) of the fax is sent over the
network.
1
59 FAX Relay Function 0=Disable
1 = Enable
2 = Each port mode
0
61 Auto Gain Control 0~5 0
62 DTMF Relay Mode
Set up information of VoIPDB is set by
Program 84-06-10.
0 = VoIPDB
1 = RFC2833
2=H.245
3=Disable
0
63 Number of G.722 audio frames 1~4
1=10ms
2=20ms
3=30ms
4=40ms
3
65 G.722 Jitter Buffer (min) 0 ~ 255 ms 30
66 G.722 Jitter Buffer (average) 0 ~ 255 ms 60
67 G.722 Jitter Buffer (max) 0 ~ 255 ms 120
68 RTP Filter 0=Disable
1 = Enable
1
69 DTMF Level mode 0 = Use the Default of VoIPDB Unit
1 = Use the Main System
0
70 DTMF Level High 1=-33dBm
:
28=-6dBm
28
71 DTMF Level Low 1=-33dBm
:
28=-6dBm
28
Conditions
None
Feature Cross Reference
None
ISSUE 1.1 SL1000
Program
84
Programming Manual 2-459
