(Continued)
DescriptionField or Graph
The management IP address for access to the main UI or AV UI over any Ethernet
network port of the switch (see Management interface IP address on page 78).
Management IP Address
The configured STP network redundancy mode of the switch (see Set the STP network
redundancy for the switch on page 82).
STP Network Redundancy
Configured Profiles
For more information about network profiles, see Network profiles on page 18.
The name of the network profile.Profile Name
The profile template on which the network profile is based.
The profile template can be any of the preconfigured profile template ( for example,
Data or Video, see Overview of preconfigured AV profile templates on page 15) or
a custom profile template (see Custom AV profile templates on page 23).
Profile Type
The VLAN ID that is assigned to the network profile.VLAN ID
The IP address that is assigned to the network profile.IP Address
The number of ports that are assigned to the network profile.# of Assigned Ports
The CPU utilization as a percentage of the CPU capacity.CPU Utilization
The memory utilization as a percentage of the total memory.Memory Utilization
Fans & Temperature
The number of internal fans depends on the switch model. The state of the fan must
be Active. If the state is not Active, there might be a problem with the fan and the
cooling.
Fans (numbered)
The temperature in Celsius that is measured by the sensor. The number of internal
sensors depends on the switch model.
Sensor (numbered)
Audio Video User Manual89Manage and monitor the switch
AV Line of Fully Managed Switches M4250 Series
