(Continued)
DescriptionLegend
This port is configured for forced multicast (see Configure the multicast mode for
one or more ports on page 42).
Force Multicast
The port reached 98 percent of its ingress or egress transmit rate.Warning
For more information about the ports, see Display detailed information about the
physical ports and LAGs on page 61.
The following table describes the information that displays in the Device Details
section, Configured Profiles section, CPU Utilization graph, Memory Utilization graph,
and Fans & Temperature section.
DescriptionField or Graph
Device Details
M4250 by default. This field is fixed.Product Name
The serial number of the switch. This field is fixed.Serial Number
The model number of the switch. This field is fixed.Model
The configured or detected date and time (see Date and time settings on page 75).Date & Time
This field does not apply to the switch (N/A).Country/Region
The MAC address of the switch. This field is fixed.Base MAC Address
The configured system name, if any (see Add a system name on page 77).System Name
The active main firmware version of the switch (see Update the firmware on page
72).
Firmware Version
The active firmware version for the AV UI. This firmware is included in the main
firmware.
AV UI Version
The active boot version of the switch. This firmware is included in the main firmware.Boot Version
The period in days, hours, minutes, and seconds since the switch was last started.System Uptime
The IP address for access to the main UI or AV UI over the out-of-band (OOB) port
of the switch (see OOB port IP address on page 80).
(This port is also referred to as the service port.)
OOB IP Address
Audio Video User Manual88Manage and monitor the switch
AV Line of Fully Managed Switches M4250 Series
