NETGEAR ProSafe FS728TP User Manual

FS728TP Smart Switch Software User Manual
Configuring the Device Using Your Browser 5-72
v2.0, November 2006
Defining VLAN Membership
The VLAN Membership Page contains a table that maps VLAN parameters to ports. Ports are
assigned VLAN membership by toggling through the Port Control settings.
To define VLAN membership:
1. Click Switch > VLAN > Membership. The VLAN Membership Page opens:
The VLAN Membership Page contains the following fields:
– VLAN ID – Displays the user-defined VLAN ID.
– VLAN Name – Displays the name of the VLAN.
– VLAN Type – Indicates the VLAN type. The possible field values are:
– Static – Indicates the VLAN is user-defined.
– Default – Indicates the VLAN is the default VLAN. The default VLAN is enabled.
– Port – Indicates the port membership.
– Giga – Indicates the Giga membership.
Figure 5-49

NETGEAR ProSafe FS728TP Specifications

General

Model	FS728TP
PoE Ports	24
PoE Budget	192W
Switching Capacity	12.8 Gbps
Forwarding Rate	9.5 Mpps
MAC Address Table Size	8K
VLAN Support	Yes
QoS	Yes
Rack Mountable	Yes
Jumbo Frame Support	Yes
Power Supply	Internal
Humidity	10% to 90% non-condensing
Management	Web-based, SNMP
Dimensions	440 x 43 mm
Operating Temperature	0°C to 40°C
Weight	3.7 kg
