30
Presets
Many expression pedals include dual TRS outputs, each one associated
with different parameters such as heel-toe sweep control or a physical
toe-switch.
Connecting each TRS output of an expression pedal to both EXP inputs
of Quad Cortex allows you to control a parameter position and bypass
the device block with the toe-switch at the same time.
1. Connect both TRS cables to EXP1 and EXP2 inputs of Quad Cortex.
Swipe down the screen to access the I/O Settings menu. Calibrate both
POSITION knobs then save the changes.
2. Tap a block on The Grid, tap the contextual menu, then select
“Assign Expression Pedal”. Choose the Expression input 1. If the TRS
connected to it corresponds to the heel-toe sweep, assign it to the
parameter you want to control.
Tap when you are ready.
3. Tap the same block on The Grid, tap the contextual menu, then select
“Assign Expression Pedal” again. Choose the Expression input 2 this
time. If the TRS connected to it corresponds to the physical toe-switch,
assign it to the BYPASS parameter.
4. Select the Switch mode then press the toe-switch. You can revert
the range if the value is inverted. Turn on the LATCH EMULATION if the
expression pedal includes a momentary toe-switch.
Can a single expression pedal with dual TRS
outputs be connected to Quad Cortex?
