Neural DSP Quad Cortex - Clipping Alert; The Directory

23
Presets
In this particular case, both input IN 1 and output SEND 1 are
clipping. Decreasing the IN 1 LEVEL [dB] value on the I/O Settings
screen will solve the problem on Row 1. On Row 2, one or more
device blocks could be clipping. Checking and changing the device
block parameters will solve the problem.
1
Send
1
In
1
Send
2
In
PRESET
A
A1 Clipping
The Directory
Tap the Preset name on The Grid to open the Directory.
PRESET
A
D3 Beast Lead
1/2
Out
1
In
DoneDirectory New SetlistSearch
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
17 18 19 20
21 22 23 24
25 26 27 28
BANK
Recent
Factory Library
0
DEVICE DIRECTORIES
My Presets
1
New Setlist
2
Factory Captures 1
Favourites
6A Whatup
6B Preset 2
6C Best Machine Riff
6G Trashpanda
6H Heavy Slow Low
6D Echo Laser
6E Doesn't Fuzz
6F Animals as Presidents
In order to keep your signal flow safe, input and output blocks will
turn red if their selected I/O are clipping the signal.
Clipping Alert
