Specications

Mic/Inst Inputs 1-2

Send Outputs 1-2

Return Inputs 1-2

Analog Outputs 1-2

Analog Outputs 3-4

• Connectors: (2) XLR-F + ¼” TS with Ground Lift

• TS Impedance: 10KΩ - 10MΩ

• XLR Impedance: 9.4K Ω

• Max Input Gain: +60 dB

• Connectors: (2) ¼” TRS with Ground Lift

• Impedance: 1M Ω

• Max Input Gain: +60 dB

• Connectors: (2) XLR-M with Ground Lift

• Impedance: 560 Ω

• Max Output Level: +9.5dBu

• Connectors: (2) TRS

• Impedance: 560 Ω

• Max Output Level: +15.5dBu balanced, +9.5dBu unbalanced

• Connectors: (2) ¼” TRS (Ground-cancelling outputs)

• Impedance: 560 Ω

• Maximum Output Level: +9.5dBu

Headphone Output

• Connectors: ¼” TRS

• Output Power (max): 300mW

For more information check the

FAQ: How can I take advantage

of the Ground-Cancelling

outputs (Send 1-2)?
