Neural DSP Quad Cortex - Four Cable Method (4 cm)

62
Setup Examples
Four Cable Method (4cm)
The four cable method allows you to use effects in different stages
of the signal chain (pre and post) in conjunction with an amplier
and cabinet. The Quad Cortex will be used as an effects processor,
therefore the Presets created for this purpose don’t need amp or
cab device blocks. This method allows you to place pre effects
tools such as overdrives, noise gates, and pitch shifters before the
amplier. Post effects such as reverbs and delays will sound after
the amp.
You will need four TS cables for making the connections:
1. Add an FX Loop device block. Choose FX Loop 1.
2. Add device blocks before and after the FX Loop block.
3. Set the output block as Out 3.
1. Connect your instrument to INPUT 1.
2. Connect OUT 3/L to the amplier’s FX return.
3. Connect SEND 1 to the amplier’s input.
4. Connect RETURN 1 to the amplier’s FX send.
