Neural DSP Quad Cortex - Top View; Rear View; Bottom View (Inside)

6
Overview
29cm
19cm
1
2
3
Bottom Dimensions:
29 x 19cm / 11.4” x 7.4”
1
2
3
IEEE 802.11 b/g/n Wi-Fi
module (2.4GHz ISM band)
4x SHARC®+ & 2x ARM
Cortex-A5 cores
USB Audio Class 2.0
Compliant
29cm
19cm
Top View Dimensions:
29 x 19cm / 11.4” x 7.4”
Power Button
7” display
Volume Wheel
11 stainless steel stomp +
rotary actuators
Chassis made of anodized
aluminum
1
2
3
4
5
Rear View Dimensions:
29 x 4.9cm / 11.4” x 1.9”
Dual Combo Inputs: TS,
TRS, and XLR
Dual FX-loops
1/4” TRS Outputs
Capture Output
Headphones Output
XLR Outputs
MIDI In, Out/Thru
Dual Expression Inputs
USB Type-B
Power Input
(12V-3A)
1
2
3
4
5
6
7
8
9
10
1
3
4
5
2
1
2 3 4 8
9 10
5
6 7
29cm
4.9cm
Top View
Rear View
Bottom View (Inside)
