The output HUD provides a wealth of useful information about the video stream assigned to the
monitor. It may include any of the following tags:
Name – the output name, as supplied in Output Configuration (see Section 7.1.1).
CONTROL – When this label appears, it indicates whether A, B, or A+B buttons are
pressed on the control surface. In turn, this serves as a reminder as to which of the two
independent outputs is being controlled at the moment, or whether both are. (See
Section 8.5 for more on Control Modes.)
Current transport mode (always shown) – one of the following:
1. PLAY
2. LIVE
3. DELAYED
4. STOP
Clips List or Play List details:
1. CLIPS mode
Clip ID# and Memo
2. LIST mode
Clip ID# and Memo
Time display:
1. LIVE or DELAYED mode (Live button on control surface is pressed):
Timecode at the current frame
Or Behind Live time (Delayed mode only)
2. CLIPS mode (Clips button on control surface is pressed):
Countdown to playback end.
(Recorded) Timecode at current frame
3. PLAY LIST mode (PLAY LIST button on control surface is pressed):
Countdown to playback end.
Timecode at current frame (from file)
Speed: Shows the T-bar position during play, as a percentage.
