Page | 11
Figure 7 – 3Play™ 425
Record up to either four or eight sources (audio and video), freely choosing between SDI
and analog HD (or SD) cameras.
Capture and play back 16:9 and 4:3 formats in both HD and SD sessions.
Output HD sessions as SD (4:3 or 16:9) and HD simultaneously from HD sessions.
Play list module supports inserting pre-recorded video, sound and imagery into your live
productions.
Send output from 3Play™ to a network connected TriCaster™.
3PLAY™ 820
Supplemental Aux (Auxiliary) Video output to a projection system or secondary monitor
at session resolutions up to 1920x1080.
2.6.3 MONITORING
Figure 8
The Replay Desktop includes two large output monitors, labeled Output A and B, with associated
controls. Tabs above the monitor group at left allow you to freely toggle between viewing:
