NIBE FIGHTER 1250
Menu 5.11.2 Brine-pump cont.sign [E]
The brine’s pump’s speed in percent.
Setting the speed during manual control.
The value is adjustable between 1 and 100 %
Menu 5.11.3 Brine-pump man. Cont. [E]
Select ”On” to manually control the brine pump.
Selection option Off and On.
- Factory setting: Off
Menu 5.11.4 BrineDiffAt min freq [S]
Select the brine temperature difference at lowest compres-
sor frequency.
The value is adjustable between 1.0 and 6.0 °C
- Factory setting: 2.5 °C
Menu 5.11.5 BrineDiffAt max freq [S]
Select the brine temperature difference at highest compres-
sor frequency.
The value is adjustable between 1.0 and 6.0 °C
- Factory setting: 4.5 °C
Menu 5.11.6 BrineDiff regP [S]
Select P part for Brine pump regulator.
The value can be set between 1 and 20.
- Factory setting: 2
Menu 5.11.7 BrineAdvanceRegP [S]
Select feed forward value of CompFreq to the brine pump
regulator.
The value can be set between 0 and 100.
- Factory setting: 20
Menu 5.11.8 BrineDiffregKstepval [S]
To select threshold value on CompFreq change when feed
forward to the brine pump regulator is to be used.
The value can be set between 1 and 10.
- Factory setting: 4
Menu 5.11.9 Brine ret. temp./MIN [E]
The lowest permitted outgoing brine temperature is set
here.
The value is adjustable between -10 and 12 °C
- Factory setting: -10 °C
Menu 5.11. 10 Autoreset brinealarm [E]
Automatic restart after an BR alarm, when the temperature
rises 3 °C above the selected alarm level (menu 5.11.9) for
brine out is selected here.
Selection option Off and On.
- Factory setting: Off
Menu 5.11.11 Return [E]
Pressing the enter button returns you to Menu 5.11.0
Menu 5.12.0 Compressor freq [E]
The current compressor frequency is shown here.
Menu 5.12.1 Inverter temperature [E]
The current inverter temperature is shown here.
Menu 5.12.2 Power in W [E]
Actual supplied power to inverter shown here.
Menu 5.12.3 Comp phase current [E]
Shows actual phase current between inverter and compres-
sor.
Menu 5.12.4 VDC link [E]
The actual internal DC in the inverter is shown here.
Menu 5.12.5 Comp load I2T [E]
Shows the compressor load.
Menu 5.12.6 Comp energy [E]
The compressor’s accumulated energy consumption in
kWh. Note! Only the compressor’s consumption applies.
Circulation pumps, control and electrical addition do not
apply.
Menu 5.12.7 Return [E]
Pressing the enter button returns you to Menu 5.12.0
Menu 5.13 Return [N]
Pressing the enter button returns you to Menu 5.0
